| Grade | Chemical composition（%） | Thickness (mm) |
|||
| ASTM | Cu | Ni | Si | Zn | 0.08-5.0 |
| C19005 | Balance | 1.5 | 0.3 | 0.4 | |
| Physical properties | |||||
| Density (g/cm³) |
Modulus of elasticity (GPa) |
Thermal expansion coefficient (×10-6/K) |
Electrical conductivity (%IACS) |
Thermal conductivity W(m·K) |
|
| 8.88 | 130 | 17.6 | 64 | 250 | |
| Mechanical properties | Bend properties | |||||
| Temper | Hardness HV0.2 |
Tension test | 90°R/T(Thick≤0.5mm) | |||
| Tensile Strength Rm/MPa |
Yield Strength MPa |
Elongation % |
Good way | Bad way | ||
| R400 | 120-150 | 400-460 | ≥360 | ≥10 | – | – |
| R490 | 140-170 | 490-550 | ≥410 | ≥10 | – | – |
| R520 | 150-180 | 520-590 | ≥440 | ≥9 | – | – |
| R580 | 170-200 | 580-650 | ≥540 | ≥8 | – | – |
